AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet
  • AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet
  • AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet
  • AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet
  • AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet

AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet

Product Details
Application:
Stadium And Airport Ceiling
Materials Grade:
G350 / G450
Thickness:
0.80mm BMT
AZ Coating:
AZ150 G/sqm
Paint Coating:
30 Micron μm
Paint System:
HDP
Paint Brand:
VALSPAR
Highlight:

AZ150 HDP Color Coated Steel Coil

,

pre painted galvanized steel sheet

,

AZ150 HDP pre painted galvanized steel sheet

Payment & Shipping Terms
Minimum Order Quantity
16 MT
Price
1000 USD/MT
Packaging Details
Standard Exporting Package with Wooden Pallet
Delivery Time
30-40 DAYS
Payment Terms
L/C, T/T
Supply Ability
500MT/DAY
Product Description

AZ150 HDP Pre-Painted Galvanized Steel Sheet for Roof panels 30 year quality warranty Valspar

Products Introduction

HDP High durable polyester Colour steel Plate, also called High Performance Colour Coated Plate, is a metal baked colour coated plate made by using HDP High Weather Resistant (High-durable polyester) Polyester paint coated on metal plate and then baked at high temperature. Due to the different resin molecular structure between high weathering polyester and common polyester, high weathering polyester has better performance in resisting ultraviolet destructive force and better durability, and its main performance is between polyester and fluorocarbon, and its weathering resistance is more than 15 years.



Scope of application

Because of its good corrosion resistance and UV resistance, HDP high weathering colour coated sheet is mainly used in chemical, metallurgy, electric power and other industries with high requirements for UV and corrosion resistance, as well as in areas with high salt fog and high altitude.



DECHO building colour steel plate can meet the need to use colour steel plate as raw material for building. DECHO BUILDING MATERIALS colour steel plate is mainly processed into, for example, colour steel corrugated board or colour steel composite sandwich board after our colour steel plate is widely used in the construction of airports, freezers, steel plants, warehouses, and other industrial buildings and commercial buildings, such as the roof of the colour steel tiles, colour steel plate sandwich walls and doors.



Reasons for choosing Huanyu new material:

  1. Provide extremely rich colour choices

  2. The paint surface is long-lasting and bright

  3. Surface coating will not fall off after stamping and has good hardness with strong ductility and is not easy to scratch.

  4. with excellent weather resistance, corrosion resistance, is to ensure the durability of the premise of the building

  5. DECHO BUILDING MATERIALS for the manufacturer direct sales

  6. The colour is customized by customers;

  7. Thickness and width have a variety of options;

  8. We provide whole rolls and cut boards for sale;







Index

Pre-Painted Galvanized/ Galvalume / Aluminum Sheets & Coils

Thickness

Base Metal : GI: 0.20-1.70mm; GL: 0.20-1.50mm

Base Metal: Aluminum 0.30-3.0mm

Width

600~1500mm

Zinc Coating

Z40~Z275 g/㎡

AZ30~AZ200 g/㎡

Paint Structure

2/1, 2/2, 3/2, 3/3

Paint Coating

Top side: 15μm~55μm

Back side: 5μm~30μm

Paint System

RMP, PE, SMP, HDP, PVDF

Paint Brand

PPG

Beckers

AkzoNobel

Valspar (Sherwin-Williams)

Chinese local brands

Paint surface

Gloss RAL color system

Textured/Matt/Wrinkle Surface

Printch Pattern Colors-Wood, Brick, Stone grains.

Coil weight

2 ~ 10 tons

Packing

Standard export packing ( Eye to Side)

Vertical Packing ( Eye to Sky) with wooden pallet

Horizontal Packing ( Eye to Side) with wooden pallet

MOQ.

16 tons/color/size



AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet 0AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet 1

AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet 2





AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet 3



AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet 4

AZ150 HDP Color Coated Steel Coil Pre Painted Galvanized Steel Sheet 5
