G40=Z120 Zinc Coated Galvanized Steel Sheet In Coil 0.90mm Thickness For Floor Bearing Deck Construction Building
  • G40=Z120 Zinc Coated Galvanized Steel Sheet In Coil 0.90mm Thickness For Floor Bearing Deck Construction Building
  • G40=Z120 Zinc Coated Galvanized Steel Sheet In Coil 0.90mm Thickness For Floor Bearing Deck Construction Building
  • G40=Z120 Zinc Coated Galvanized Steel Sheet In Coil 0.90mm Thickness For Floor Bearing Deck Construction Building
  • G40=Z120 Zinc Coated Galvanized Steel Sheet In Coil 0.90mm Thickness For Floor Bearing Deck Construction Building

G40=Z120 Zinc Coated Galvanized Steel Sheet In Coil 0.90mm Thickness For Floor Bearing Deck Construction Building

Place of Origin CHINA
Brand Name Decho
Certification MILL TEST CERTIFICATE
Model Number Hot-dip Galvanised steel
Product Details
COIL WIDTH:
1200 Mm
Coil Thickness:
0.90mm
Coil ID.:
508/610mm
Steel Grade:
G500
Coil Weight:
2~16tons
Sheet Length:
5.8 Metres Max
Highlight:

Z120 zinc coated galvanized steel sheet

,

Z120 zinc coated galvanized steel sheet

,

prepainted galvanized steel sheet in coil 1.5mm

Payment & Shipping Terms
Minimum Order Quantity
16 tons
Price
USD 580~800
Packaging Details
Horizontal package With Wooden Pallet
Delivery Time
30~45days
Payment Terms
L/C, T/T
Supply Ability
800tons/ day
Product Description
G40=Z120 Zinc Coated Galvanized Steel Sheet In Coil 0.90mm Thickness For Floor Bearing Deck Construction Building

What is hot-dip galvanised steel?

Hot-dip galvanising is a process that involves coating steel with a thin layer of zinc to prevent rust from forming. The surface treatment is achieved by passing the steel through molten zinc at high temperature, providing long-term protection for steel products.

The zinc coating has a corrosion resistance and sacrificial corrosion function that delays the production of red rust. The zinc layer of hot-dip galvanised steel is higher than that of electro-galvanised sheet steel, giving it better corrosion resistance.


Steel deck overview



Floor decking sheets is also known as profiled steel deck,metal deck,roof decking, etc.The earliest name of bondek is called corrugated steel deck,and all steel floor decking sheets that are pressed and formed by a platen press and are collectively referred to.The floor slab is made from galvanized steel sheet by cold roll forming,and its cross section is V-shaped, U-shaped, trapezoidal or the like. It is mainly used as a permanent template and can also be selected for other purposes.The earliest compacted steel decking sheets were mainly used as roof panels of factory roof,followed by profiled steel plates used for the floors and gradually classified as floor decking sheets.



Galvanized Corrugated Steel Deck Sheet is one kind of bondek sheets for multiple high-rise buildings,which is also called steel floor decking or bondek slab.Our quality composite decking sheets have full set of technical suppor
Steel standards Yield Strength(MPa) Tensile strength (N/mm²)
Q235 ≥235 215
Q345 ≥345 300
G500 ≥500 520
G550 ≥550 550





Applications for hot-dip galvanised steel sheet and coil
  • Automotive
  • Pipes and tubes
  • Exterior cladding
  • Agriculture
  • Construction
Advantages of hot-dip galvanised steel sheet and coil
  • Excellent formability
  • Outstanding corrosion resistance
  • Consistent quality
